SUPERMICRO SYS-2028R-C1R Żory

Poniżej prezentujemy szczegółowy opis techniczny oferowanego produktu: Product SKUs SYS-2028R-C1R SuperServer 2028R-C1R (Black) Motherboard Super X10DRH-CProcessor/Cache CPU Intel® Xeon® processor E5-2600 v4†/ v3 family (up to 145W TDP) * Dual Socket R3 (LGA 2011) Cores / Cache Up to 22 Cores† / Up to 55MB† Cache System Bus QPI up to 9.6 GT/s Note † BIOS version 2.0 or above is required Note * Please contact Supermicro Technical Support for additional information about frequency optimized CPUs and specialized system optimization. System Memory Memory Capacity 16x 288-pin DDR4 DIMM slots Up to 2TB† ECC 3DS LRDIMM, 512GB ECC RDIMM Memory Type 2400†/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit DIMM Sizes RDIMM: 32GB, 16GB, 8GB, 4GB LRDIMM: 64GB, 32GB 3DS LRDIMM: 128GB Memory Voltage 1.2 V Error Detection Corrects single-bit errors On-Board Devices Chipset Intel® C612 chipset SATA SATA3 (6Gbps); RAID 0, 1, 5, 10 SAS LSI 3108 SAS3 (12Gbps) controller; HW RAID 0, 1, 5, 6, 10, 50, 60 IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC Network Controllers Intel® i350 Gigabit Ethernet Virtual Machine Device Queues reduce I/O overhead Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output Graphics ASPEED AST2400 BMC Input / Output SATA 8x SATA3 (6Gbps) ports SAS 8x SAS3 (12Gbps) ports LAN 2x RJ45 Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port USB 2x USB 3.0 ports (2 rear) 4x USB 2.0 ports (2 rear, 2 front) 1x USB Type A Video 1x VGA Connector Serial Port / Header 2x Fast UART 16550 serial 2x COM Ports (1 rear, 1 front) System BIOS BIOS Type 128Mb SPI Flash EEPROM with AMI® BIOS BIOS Features Plug and Play (PnP) APM 1.2 DMI 2.3 PCI 2.2 ACPI 1.0 / 2.0 USB Keyboard support Hardware BIOS Virus protection SMBIOS 2.3 UEFI RTC (Real Time Clock) Wakeup Chassis Form Factor 2U Rackmount Model CSE-213AC-R920LPB Dimensions and Weight Height 3.5" (89mm) Width 17.2" (437mm) Depth 24.8" (630mm) Package 10.5" (H) x 26.5" (W) x 38" (D) Weight Net Weight: 38 lbs (17.4 kg) Gross Weight: 63 lbs (28.8 kg) Available Color Black Front Panel Buttons Power On/Off button System Reset button LEDs Power LED Hard drive activity LED 2x Network activity LEDs System Overheat LED / Fan fail LED / UID LED Expansion Slots PCI-Express 1x PCI-E 3.0 x16 6x PCI-E 3.0 x8 (Low-profile AOC) Drive Bays Hot-swap 8x 2.5" SAS3 and 8x 2.5" SATA3 Hot-swap drive bays Peripheral Optional DVD-ROM drive supports 1x slim or 1x 5.25" DVD drive System Cooling Fans 3x 8cm heavy duty fans with optimal fan speed control Power Supply with Power Distributor 920W high-efficiency (94%+) AC-DC Redundant power supplies with PMBus and I2C AC Input 100-240 V, 50-60 Hz, 11-4.5 Amp DC Output 4 Amp @ +5V standby 75 Amp @ +12V Certification Platinum Certified [ Test Report ]PC Health Monitoring CPU Monitors for CPU Cores,+1.5V, +3.3V, +5V, +12V, +5 Stdby, +3.3 Stdby, VBAT, Memory Voltages. CPU Core 6-Phase-switching voltage regulator FAN Total of five 4-pin PWM fans 5x fans with tachometer monitoring Status monitor for speed control Status monitor for on/off control Low noise fan speed control Temperature Monitoring for CPU and chassis environment CPU thermal trip support Thermal Control for 10x Fan Connectors PSU I2C temperature sensing logic Thermal Monitor 2 (TM2) support PECI LED Power Fail / Overheat LED Suspend-state Indicator LED UID LED Other Features SDDC Support Operating Environment / Compliance RoHS RoHS Compliant Environmental Spec. Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) UWAGA !!! Oferowany produkt to platforma serwerowa służąca do budowy swojej własnej konfiguracji serwera ( nie zawiera CPU, RAM czy HDD ). Jeżeli potrzebujesz kupić gotowy serwer wraz z CPU, RAM, HDD/SDD oraz innymi opcjami koniecznie wyślij do nas zapytanie. Posiadamy najlepsze ceny i dostępność na pełne konfiguracje. Zapewniamy pełne wsparcie techniczne do zakupionych u nas serwerów.
