Supermicro SuperChassis 213XAC-R1K05LP (CSE213XACR1K05LP) Bochnia

Poniżej prezentujemy szczegółowy opis techniczny oferowanego produktu: Product SKUs CSE-213XAC-R1K05LP SuperChassis 213XAC-R1K05LP (black) Form Factor 2U rackmount chassis - supports for maximum motherboard sizes: 15.12" x 13.2" Processor Support Dual and Single Intel® and AMD processors Dimensions Height 3.5" (89mm) Width 17.2" (437mm) Depth 25.6" (650mm) Packaging 27 (W) x 14.8(H) 37.3 (L) Gross Weight 58 lb (26.31 kg) Available Colors black Expansion Slots • 11 low-profile expansion slot(s) Drive Bays Hot-swap 16x 2.5" hot-swap SAS/SATA drive bay w/ full SES-II support on SAS motherboards Backplane • BPN-SAS3-213A Peripheral Drives DVD-ROM • 2 Optional USB 2.0 ports • 1 Optional standard 5.25" drive bay • 1 Optional COM port tray • 1 Optional slim DVD-ROM drive bay Front Panel Buttons • Power On/Off button • System Reset Button LEDs • 2 Network Activity LEDs • HDD activity LED • Power Status LED • System Information LED Server(s) for SC213XAC-R1K05LP 2028R-TXR System Cooling Fans 4x 8cm high-performance PWM fans System Monitoring Chassis intrusion switch Operating Environment (System) Operating Temperature Range 5°C - 35°C (41°F - 95°F) Non-Operating Temperature Range -40°C - 70°C (-40°F - 158°F) Operating Relative Humidity Range 8% - 90% (non-condensing) Non-Operating Relative Humidity Range 5% - 95% (non-condensing) PowerStick Power Supply 1000W Redundant Power Supplies with PMBus Total Output Power 800W/1000W Dimension (W x H x L) 38 x 40 x 360 mm Input 100-127Vac / 9-7.5A / 50-60Hz 200-240Vac / 6-5A / 50-60Hz +12V Max: 66.7A / Min: 0A (100-127Vac) Max: 83A / Min: 0A (200-240Vac) +5Vsb Max: 4A / Min: 0A Output Type Gold Finger Connector (16 Power Pin, 14 Signal Pin) Certification UL/cUL/CB/BSMI/CE/CCC Titanium Level (Cert. in progress)Regulatory (Power Supply) Power Supply Safety / EMC USA - UL listed Canada - CUL listed Germany - TUV Certified EN 60950/IEC 60950-Compliant CB Report CCC Certification
